This unique, all-in-one, solar street light is available with a choice of a 20 Watt (2,600 Lumen), 30 Watt (3,900 Lumens) or a 40 Watt (5,200 Lumen) LED lamp. Sold as a complete system. This compact, unique, easy to install all-in-one integrated solar street light can be pole, post or wall mounted. Automatically illuminates at dusk with a choice of three selectable user modes. Choice of three different models. Prices from $699.99.
This compact, self-contained, integrated, all in one solar street light fixture is offered in three different models (20W, 30W and 40W). It consists of a discrete solar panel installed on the top on the fixture, with a lithium battery installed inside, and a cluster of powerful white SMD/LEDs on the under-side of the unit. Also, on the under-side of this solar powered street light is a motion sensor. This solar powered area light offers three different modes which can be selected by the installer or end-user with the supplied remote control. Timed mode. This provides automatic illumination at dusk at 100% output for the first 2 hours, then 70% output for the next 2 hours, then 30% output for the next 8 hours, then off. Motion sensor mode. This provides automatic illumination at dusk at 30% output with 100% output upon motion detection for the first 2 hours, then 30% output with 70% output upon motion detection for the next 2 hours, then 10% output with 30% output upon motion detection. Mixed mode. This provides automatic illumination at dusk at 100% output for the first 2 hours, then 70% output for the next 2 hours, then 10% output for the next 8 hours with 30% output upon motion detection. This all-in-one integrated solar street light fixture may be a good choice for windy locations based on is compact, integrated design. Choice of three different models. Color of product is gray. Color of light output is white.
Popular Uses
All in one solar street lights are perfect for small streets, parking lots, open areas, playgrounds, parks, HOA's etc. They can be used to provide general lighting and security lighting around commercial buildings. Small model can be used for residential applications for lighting yards, walkways and driveways.
Technical Specifications
Performance
All-in-one design.
Weather rating is I.P. 65
Ideal operating temperature charging range is 0 deg C. to +60 deg C. (-32 deg F. to +140 deg F.).
Ideal operating temperature discharging range is -20 deg C. to +60 deg C. (-4 deg F. to +140 deg F.).
Ideal storage temperature range is 0 deg C. to +45 deg C. (-32 deg F. to +113 deg F.).
Anti-tamper (theft resistant) stainless steel hardware included for pole clamp.
Anti-tamper bolt install/release tool included.
Light Fixture
Unique all in one fixture with a choice of 20W, 30W or 40W of LED power.
A passive infra-red motion sensor is built into the fixture on all models.
Motion sensor detection range (at ground level) is up to 20' forward and with a 90 degree detection spread, up to 13' left/right.
The detection range will vary depending upon a few factors including fixture mounting height, local ambient temperature etc.
All LEDs have a color temperature of 5,550~6,000k.
LED status LEDs indicate charge, battery, and lamp status.
Pinhole on/off switch.
There are 3 mode options available which can be selected using the supplied IR remote control.
Timed mode - Automatic illumination at dusk at 100% output for the first 2 hours, then 70% output for the next 2 hours, then 30% output for the next 8 hours, then off.
Motion sensor mode - Automatic illumination at dusk at 30% output with 100% output upon motion detection for the first 2 hours, then 30% output with 70% output upon motion detection for the next 2 hours, then 10% output with 30% output upon motion detection.
Mixed mode - Automatic illumination at dusk at 100% output for the first 2 hours, then 70% output for the next 2 hours, then 10% output for the next 8 hours with 30% output upon motion detection.
The 20W model is fitted with multiple SMD/LEDs at 20w power and provides 2600 Lumens at full brightness and 900 Lumens in ambient mode.
That is equal to approximately 300 watts of incandescent lighting.
The 30W model is fitted with multiple SMD/LEDs at 30w power and provides 3900 Lumens at full brightness and 1300 Lumens in ambient mode.
That is equal to approximately 400 watts of incandescent lighting.
The 40W model is fitted with multiple SMD/LEDs at 40w power and provides 5200 Lumens at full brightness and 1700 Lumens in ambient mode.
That is equal to approximately 500 watts of incandescent lighting.
These fixtures can typically illuminate continuously for up to 24 hours in ambient mode or up to 12 hours in full brightness mode.
The 40W model is approx. 45" x 13" x 2" (115cm x 33cm x 5cm) LxWxD.
The 20W model is ideal for lighting up an area approximately 60' x 60' (18m x 18m).
The 30W model is ideal for lighting up an area approximately 70' x 70' (21m x 21m).
The 40W model is ideal for lighting up an area approximately 80' x 80' (25m x 25m).
Battery
Integral high capacity Lithium battery pack pre-installed.
The system has built-in charge control regulation with over-charge and discharge protection.
Solar Panel
The 20W model is fitted with a 50 Watt solar panel.
The 30W model is fitted with a 60 Watt solar panel.
The 40W model is fitted with a 60 Watt solar panel.
Installation
Short support arm and mounting bracket is included.
Easy installation onto a round pole.
The clamp/bracket can be attached to a round pole of 2" diameter up to 3.5" diameter.
The 20W model can be installed up to a height of approx. 20'.
The 30W model can be installed up to a height of approx. 23'.
The 40W model can be installed up to a height of approx. 26'.
Can also be fitted to a square post or to a solid vertical surface such as a wall or side of a building.
The 'U' section of the clamp is removable to allow for direct surface mounting.
Remarks
With valid warranty registration, this fixture is offered with a 24 month warranty (excluding battery), in accordance with our Terms, Conditions, and Policies.
Please Note:
This product is a special order and is non-returnable except in the event of a fault (during its warranty period) when the product, once returned will be repaired or replaced.
The solar panel must be installed in a location where it can receive full direct sunshine (when available) and usually set facing South at an appropriate angle (where adjustment options allow). The solar panel must not be installed in a shaded or part shaded location and never indoors. The standard specifications of the system (particularly the solar panel Wattage and battery capacity) may need to be adjusted. These components are determined by your geographic location, power consumption (LED Wattage) and the total amount of hours of illumination time required. Such changes to the standard specifications may increase or decrease the cost shown. Please contact us for more information or assistance. The illumination time is estimated and subject to various factors including (but not limited to) geographic location, seasons, temperature, weather conditions & location of product etc. The illumination time of most solar lights can reduce during winter months when the weather is poor and the days are shorter. During this time insolation hours decrease accordingly. Shorter illumination time due to one or more of the above factors does not define the product as being ‘defective’ or ‘not as described’. All solar lights must be used in a completely dark location at night time otherwise they may not illuminate. Nearby strong lighting sources or ambient lighting may affect the operation of a solar light. This does not define the product as being 'defective' or 'not as described'. Please note, if you do not install or use this product for several months the battery may discharge naturally on its own. By allowing a battery to deep discharge it may cause irreversible damage as the battery may then lose the ability to recharge or hold a full charge. Although unlikely, we reserve the right to supply this product with any minor alterations or minor changes to the specifications (shown above by text description or by photographs) due to different supplies or product batches received, incorporating such product changes made by the manufacturer, without further notice. Descriptions, specifications and photographs are updated regularly but may not be current when minor changes to a product have only recently been made.
* View our Terms, Conditions and Polices (including our Returns Policy) for further information.
